SFS103S - Reducer/Diminishing Strip 2mm Aluminium

SFS103S -  Reducer/Diminishing Strip 2mm Aluminium

Aluminium

SFS103 2mm Diminishing Strip is designed for use where 2mm vinyl tiles or sheetgoods meet concrete slab floors.

The profile is specified to withstand heavy traffic situations that may be encountered, for example - heavy hard wheeled stock carts or trolleys, as well as shopping trolleys.

Product Specifications:

• Product Code - SFS103
• Overall Length - 3.66 metres
• Horizontal Width - 30.00mm
• Vertical Height - 2.00mm down to .50mm
• Finish - Mill Finish

Installation Instructions:

The SFS103 2mm Diminishing Strip is designed to be used in conjunction with 2mm vinyl  tiles and sheet goods, reducing down to 0.65mm. It is assumed that sub-floors have been prepared according to the relevant Australia/New Zealand Standards (ie AS/NZ 1884).

1. Recommended fastening methods are bonded, (using a moisture curing high strength urethane adhesive, or similar), or Drill & Plug using 9g x 32mm Philips head screw.
2. Firmly retain the diminishing strip against the installed tiles to ensure no gapping. Mark out in a straight line, and drill a 6mm hole through the trim, into the slab to a depth of not greater than 35mm, and secure using a plug and countersunk screw. Repeat this process down the length of the finish.
3. A bead of mastic adhesive or silicone can be applied beneath the diminishing strip to ensure that sub-floor irregularities are islolated.
